Microwave Sensor Module for LTWPLED Fittings
Product Code: LT WPMW
5055800108888
LTWPMW
Loading …
Length: 89mm
Width: 38mm
Height: 24mm
LEDlite
Microwave Sensor Module for LTWPLED
Microwave Sensor Module for LTWPLED
Plug & play microwave sensor for LTWPLED non corrosive weatherproof LED fittings.
- Operating voltage: 220-240VAC, 50/60Hz
- Maximum load: 400W @ 220VAC
- Stand-by power: <0.5W
- Operation mode: ON/OFF
- Microwave frequency: 5.8GHz±75MHz
- Microwave power: <0.3mW
- Sensitivity: 100% / 50%
- Hold time: 5s/1min/3min/10min
- Daylight threshold: Disable/50lux/25lux/10lux
- Mounting height: max. 5m(ceiling), 1.5-1.8m (wall)
- Detection radius: max. 6m (ceiling mounted 3m)
max. 10m (wall mounted 1.8m) - Detection angle: 30° to 150°
- Operating temperature: -35°C to 70°C
- IP rating: IP20
- Warranty: 5 years
Length: 89mm
Width: 38mm
Height: 24mm
Technical:LTWPMW Datasheet - 560kb pdf LTWPMW Instructions - 2.5mb pdf |
|
Product Code
Description
|
Price (ex VAT)
Price (inc VAT)
Quantity
|
|---|---|
|
LT WPMW
Microwave Sensor Module for LTWPLED Fittings |
