20 Way Metal Consumer Unit c/w 100A Main Switch
Product Code: BG F22M20
5050765159722
CF22M20-01
Loading …
Width: 496mm
Height: 233mm
Depth: 116mm
BG
20 Way Metal Consumer Unit
c/w 100A Main Switch
20 Way Metal Consumer Unit
c/w 100A Main Switch
This range of all metal consumer units offer a flexible solution for the 18th Edition Wiring Regulation BS7671.
Available in a number of sizes from 7 way to 20 way, these consumer units will suit all applications.
Each unit has an integrated spirit level, aiding installing without additional tools.
Supplied with 100A Main Switch, busbar, label sheet, 2 cover blanks and instructions.
MCBs, RCDs, RCBOs and control devices can be fitted into the consumer units.
Available in a number of sizes from 7 way to 20 way, these consumer units will suit all applications.
Each unit has an integrated spirit level, aiding installing without additional tools.
Supplied with 100A Main Switch, busbar, label sheet, 2 cover blanks and instructions.
MCBs, RCDs, RCBOs and control devices can be fitted into the consumer units.
- Max. current rating: 100A
- Operating voltage: 230V AC 50Hz
- Short current withstand: 16kA rms
- Main switch terminal: 35mm² capacity
- Main switch torque: 2.5 Nm
- IP rating: IP2XC
- Material: Steel
- Finish: White gloss (matches BG white accessories)
- Each unit is supplied with 2x cover blanks
- Knockouts:
Top & bottom face - 13 x Ø20mm, 2 x Ø32mm
Sides - 1 x Ø32mm
Base - 3 x Ø35mm x 90mm
Width: 496mm
Height: 233mm
Depth: 116mm
|
